Programmering
– 4 Encoders – Vertrouwde toetsen en numeriek toetsenbord – Kleurenkiezer – Filterbibliotheken van Lee, Rosco en Apollo – Gobo Picker – Door gebruiker te definiëren groepen – Door gebruiker te definiëren voorinstellingen – Effectenengine – Ventilatorfuncties – Ingebouwde Inrichtingsbibliotheek
Weergave
– 10 faders met meerdere pagina’s – Go en Pause/Reverse keys – 10 executer keys met meerdere pagina’s – 4 door de gebruiker te definiëren master faders – Cue list scherm
Technical Features:
• Familiar keys, numeric keypad and 4 Encoders
• 10 Playback faders with Go, Pause/Reverse, Flash keys on multiple pages
• 10 Executer/Flash keys on multiple pages
• Colour picker, Swatchbook by Lee, Rosco and Apollo Filters
• Gobo Picker
• User definable groups and presets
• User definable display layout
• 4 user definable master faders
• Effects engine
• Fan functions on all attributes
• Built-in Fixture builder
• Cue list screen
Connectors
• 2 x DMX 5-pin opto-isolated in/outs (RDM ready)
• RP-SMA W-DMX antenna output
• Ethernet/Artnet
• 2x HDMI monitor out
• Midi In/Thru/Out 5-pin DIN
• Audio Input 3-pin XLR
• IEC Power Supply Input
• 2 x Dimmable Desklight outputs 3-pin XLR
• 3 x USB-B connectors
Software
• 2 universe 1024 channels DMX
• 100 Fixtures
• 5000 memories
• 200 memory stacks
• 100 groups
• 9 x 100 presets (position, colour, beam, effects, etc.)
• Command line interface
• Output visualizer
• Libraries provided by AtlaBase Ltd (> 17.500 fixtures)
• Tracking and non-tracking options
Physical
Housing: Metal & flame-retardant plastic side covers
Dimensions: 400 x 575 x 160mm (LxWxH)
Weight: 9Kg
Ambient Temp. Range: 0 ~ 35°C
Storage Temp. Range: -5 ~ 45°C
